VIBRATION
SMART SENSOR
High Sensitivity Vibration Sensor
Predictive Maintenance
Robotics
Transfer Machines
Rotary Machinery
Conveyor Lines
Shaft and Reduction Gear
Condition Based Maintenance
ABOUT
The VD 102 is a high sensitivity vibration sensor specially designed by ALTERIA for predictive maintenance of robotic machinery, industrial reduction gear, and small rotary machinery.
This is an embedded edge smart sensor with patent pending pre-processing algorithmic that forwards data such as the frequency of each vibration event, its bandwidth, its amplitude with respect to the level of background noise in a simplified form in order to save resources on connectivity and postprocessing.
Sensor Network
Its design allows the installation of hundreds of sensors networked to a Gateway (hub) that is connected to a local server or to an on the cloud server.
FEATURES
Very sensitive
Five times more sensitive than sensors based on accelerometers
Precise
High noise immunity, featuring excellent roll off highfrequency filtering
Smart
With embedded edge pre-processing technology saves 93% of the data payload required
Flexible
Forwards data through an industrial wireless system or serial port
Non-intrusive
No installation. Just secure the sensor with adhesive to the machinery
Reliable
Employs top quality parts manufactured in the U.S. and Europe.
SPECIFICATIONS
Physical variables:
- Vibration Frequency
- Amplitude
- Bandwidth
- Background noise level
Power: Databus, 5 Volt
Rate: 1000 Samples / Second
Process: FFT Algorithm
Bandwidth: 5 to 300 Hz +/- 1dB
Output: Digital in the desired format
Connectivity: MESH Network
Wireless: sub Ghz or wired Serial
Range: 3 kilometers without repeaters
Security: Double encryption
Dimensions: 90 x 33 x 30 mm
Weight: 0.5 Kg
Environmental: IP 67, resistant to aggressive environments
Physical: ABS plastic box
Temperature range: -20 C / 65C
