VOLTAGE/CURRENT
SMART SENSOR
Non-Intrusive AC Three Phase
True RMS Sensor Pod
Real time industrial power supply monitoring
Report supply failure
ABOUT
The SCA 105 is a combined voltage and current sensor for use in alternating current three-phase industrial power systems.
Sampling in real time an algorithm calculates voltage and current true average values (RMS) of each phase or leg.
With a 10 bit resolution (more than a thousand levels with 0.25 volt steps) is great help to get data to study power degradation patterns over time and therefore to create predictive maintenance models.
Sensor Networking
Our Mesh network allows the installation of hundreds of sensors that report to a single Gateway.
FEATURES
Accurate
1/1000 Resolution
Fast
Real-time monitoring at 120 samples/second
Very effective
Detects the degradation of power supply units, including micro-surge events
All-in-one
Three phase monitoring in one pod
Smart
The sensor is programmable and threshold alarm levels can be created
Easy to use
Forwards data through an industrial wireless system or serial port
Easy to install
Non-intrusive approach installs in 5 Minutes
Reliable
Use top quality parts manufactured in the United States and Europe
SPECIFICATIONS
Physical variables:
- AC Voltage 3 Ph 100-380 Voltios
- AC Current 3 Ph 10-500 Amp
- AC Frequency 3 Ph
- Power cuts/Micro-surge 3Ph
Power: Data bus/ 5 Volts
Reading: 120 Samples/Sec
Output: Digital in the desired format
Connectivity: Network connection
Wireless: ISTM sub GHz or wired Serial
Range: 2 Miles with standard antennas
Security: Double encryption
Dimensions: 100 x 68 x 40 mm
Weight: <2 Kg/ 4 Lb
Environmental: IP 67, resistant to harsh environments
Enclosure: ABS plastic
